This mini hunting camera with 3g Function, is a surveillance camera working automatically. It can send the pictures instantly to your mobile device or E-mail via 3g network. You’ll be alerted just when something has happened.
Most importantly, user can send SMS to control the camera remotely.
Note: To active its MMS or SMTP functions, the camera should find a signal and SIM card firstly.
|Image Sensor||8 Mega Pixels Color CMOS|
|Memory||TF Card to 32GB(not included)|
|Lens||F=3.1; FOV=120 °|
|Size||210mm * 90mm * 116 mm|
|IR-cut||Full Automatic IR Filter|
|LEDs||Low Glow 940nm|
|Night vision Range||65ft/20meters|
|Number of IR LED||48 LEDs|
|PIR Delay||1/5/10/30sec/min (default 1 sec)|
|multiple Photo on one detection||1/3/6/9|
|Selectable Image Resolution||Yes|
|Password Security||4 digital PIN code|
|Frequency Bands||2G GSM 850/900/1800/1900 MHz|
|3G UMTS/HSPA 850/900/1900/2100 MHz|
|MMS to phone||1-4 phone number|
|MMS to e-mail||1-4 email address|
|Stand-by power consumption||0.2mA|
|Interface||USB; TF Card Holder; 9V DC External|
|Operation Temperature||-30 ~+70℃|
|Power||6×AA battery, External power DC 9V(not included)|
|Moon Phase Imprint||Yes|
1.4 Key Features
1 Built-in 2.0″ TFT colour screen to review photos and videos on the camera
2 48pcs IR LEDs for flash range as 20 meters
3 Programmable 8/12/16 Megapixel high-quality resolution
4 Color pictures during daylight; black and white at night
5 Adjustable PIR sensitivity; HIGH, MID, LOW
6 Impressive quick trigger time: 0.5s
7 Multi-shot pictures; 1,3,6,9
8 Adjustable delay between motions; 1/5/10/30 seconds/minutes
9 Adjustable video length: 10/30/60/90 seconds
10 With 6pcs AA alkaline batteries, the longest standby time is up to 6 months
11 Available operation temperature: -20℃ ℃ to 60
12 With a specified Timer, the camera can be programmed to work only during preset time period every day
13 Stamp the date, time, temperature and longitude and latitude on each picture
14 Sound Recording
15 Supports 3G/2G SIM card to get real-time photos; IMEI available.
16 With MMS/SMTP function, the camera can transmit photos to 1-3 preset mobile phones or 1-3 email per trigger
17 SMS to enable the camera to shoot a photo and send back instantly, ask the camera to work or not, get the number of taken picture and battery status
USB cable ×1
CD User manual ×1
Mounting Strap ×1
Remote Control ×1
– Please insert the TF card when the camera is power off.
– Please do not insert or take out the TF card when the camera is power on.
– Recommended formatting the TF card by the camera when used the first time.
– The camera will be in USB mode when connected to a USB port of a computer. In this case, the TF card function as a removable disk.
– Please ensure sufficient power when having a firmware upgrade, otherwise, the upgrade process could be interrupted incorrectly. If any fault occurs after improper upgrading process, the camera may stop function properly.
